Using a Heat Pump For Cooling

# ============================================================================
# Dew Point Heat Pump Control — Home Assistant Package
# ============================================================================
# Sets the Samsung heat pump (climate.heat_pump_indoor) to COOL mode with a
# safe setpoint = worst-case room dew point + 2 C, then lets the heat pump
# regulate ITSELF to that setpoint. Staying at/above (highest dew point + 2 C)
# keeps every room clear of its condensation threshold; the +2 C is the safety
# buffer. The heat pump's own floor is 16 C, so the setpoint is clamped to
# 16-25 C and won't go below 16 C even if dew point + 2 is lower.
#
# ON/OFF: the heat pump is turned ON (cool) ONLY when the control toggle is
# enabled, and OFF ONLY when it is disabled. In between it stays on and cycles
# its own compressor — this automation never switches it on/off based on
# temperature; it only keeps the setpoint up to date as the dew point drifts.
#
# The circulation-pump thermostat (climate.thermostat_thermostat) is forced
# to HEAT @ 35 C while control is enabled, so it always calls for heat and
# the pump keeps circulating. It is switched OFF when control is disabled.
#
# ---------------------------------------------------------------------------
# INSTALL (this whole file lives under packages/):
#   File path:  /homeassistant/packages/dewpoint_heatpump.yaml
#   configuration.yaml must contain:
#       homeassistant:
#         packages: !include_dir_named packages
#   Then: Developer Tools -> YAML -> Reload (Template + Automations), or Restart.
#
# ALL ENTITIES NOW WIRED: hallway (Airthings), bedroom floor (ATC 7056),
# aux (living room aux sensor), and climate.heat_pump_indoor. Add more rooms
# by copying a per-room block and adding it to the "Combined" list.
# ============================================================================


# --- Master on/off switch for the whole behaviour --------------------------
input_boolean:
  dewpoint_control:
    name: Dew Point Control
    icon: mdi:water-percent


# --- Safety buffer above the worst-case dew point (adjustable slider) -------
# Setpoint = worst-case dew point + this buffer. Bigger = safer (further from
# condensation) but warmer. Rendered as a slider on the dashboard.
input_number:
  dewpoint_buffer:
    name: Dew Point Buffer
    icon: mdi:thermometer-plus
    min: 0
    max: 5
    step: 0.5
    initial: 2
    unit_of_measurement: "°C"
    mode: slider


template:
  - sensor:

      # --- Per-room dew point (Magnus formula) ---------------------------
      # To add a room: copy one block below, change the name + the two
      # entity IDs, then add sensor.<name>_dew_point to "Combined" below.

      # --- Bedroom floor: wired to the real ATC 7056 sensor --------------
      - name: "Bedroom Floor Dew Point"
        unique_id: bedroom_floor_dew_point
        unit_of_measurement: "°C"
        device_class: temperature
        state_class: measurement
        availability: >-
          {{ has_value('sensor.atc_7056_temperature')
             and has_value('sensor.atc_7056_humidity') }}
        state: >-
          {% set T  = states('sensor.atc_7056_temperature') | float %}
          {% set RH = states('sensor.atc_7056_humidity') | float %}
          {% set g  = log(RH / 100) + (17.62 * T) / (243.12 + T) %}
          {{ ((243.12 * g) / (17.62 - g)) | round(2) }}

      # --- Hallway: wired to the real Airthings Wave+ (049562) -----------
      - name: "Hallway Dew Point"
        unique_id: hallway_dew_point
        unit_of_measurement: "°C"
        device_class: temperature
        state_class: measurement
        availability: >-
          {{ has_value('sensor.airthings_wave_049562_temperature')
             and has_value('sensor.airthings_wave_049562_humidity') }}
        state: >-
          {% set T  = states('sensor.airthings_wave_049562_temperature') | float %}
          {% set RH = states('sensor.airthings_wave_049562_humidity') | float %}
          {% set g  = log(RH / 100) + (17.62 * T) / (243.12 + T) %}
          {{ ((243.12 * g) / (17.62 - g)) | round(2) }}

      # --- AUX temperature sensor (living room) --------------------------
      - name: "Aux Dew Point"
        unique_id: aux_dew_point
        unit_of_measurement: "°C"
        device_class: temperature
        state_class: measurement
        availability: >-
          {{ has_value('sensor.living_room_aux_sensor_63be_temperature')
             and has_value('sensor.living_room_aux_sensor_63be_humidity') }}
        state: >-
          {% set T  = states('sensor.living_room_aux_sensor_63be_temperature') | float %}
          {% set RH = states('sensor.living_room_aux_sensor_63be_humidity') | float %}
          {% set g  = log(RH / 100) + (17.62 * T) / (243.12 + T) %}
          {{ ((243.12 * g) / (17.62 - g)) | round(2) }}

      # --- Worst-case dew point across ALL rooms (the binding room) ------
      # This is the MAX, so it tracks the dampest room.
      - name: "Combined Dew Point"
        unique_id: combined_dew_point
        unit_of_measurement: "°C"
        device_class: temperature
        state_class: measurement
        state: >-
          {% set ids = [
            'sensor.hallway_dew_point',
            'sensor.bedroom_floor_dew_point',
            'sensor.aux_dew_point'
          ] %}
          {% set vals = ids | map('states')
                            | reject('in', ['unknown', 'unavailable', 'none'])
                            | map('float') | list %}
          {{ (vals | max) if vals else none }}


automation:

  # --- Main loop: keep setpoint current; run only when room needs it -------
  - alias: "Heat pump – dew point setpoint"
    id: heatpump_dewpoint_setpoint
    mode: single
    triggers:
      # Re-evaluate on a fixed 30-min cadence so the setpoint isn't nudged
      # up/down on every dew-point reading. Manual actions below still apply
      # immediately (enabling control, moving the buffer slider).
      - trigger: state
        entity_id: input_boolean.dewpoint_control
        to: "on"
      - trigger: state
        entity_id: input_number.dewpoint_buffer   # re-apply when buffer changes
      - trigger: time_pattern
        minutes: "/30"           # re-evaluate setpoint every 30 minutes
    conditions:
      - condition: state
        entity_id: input_boolean.dewpoint_control
        state: "on"
      - condition: template
        value_template: >-
          {{ states('sensor.combined_dew_point')
             not in ['unknown', 'unavailable', 'none'] }}
    variables:
      climate_entity: climate.heat_pump_indoor
      hvac_mode: cool             # Samsung unit cools toward the safe setpoint
      offset: >-                  # degrees C ABOVE the worst-case dew point (slider)
        {{ states('input_number.dewpoint_buffer') | float(2) }}
    actions:
      - variables:
          target_temp: >-
            {% set dew = states('sensor.combined_dew_point') | float %}
            {% set raw = dew + (offset | float(2)) %}
            {% set tmin = state_attr(climate_entity, 'min_temp') | float(16) %}
            {% set tmax = state_attr(climate_entity, 'max_temp') | float(25) %}
            {% set clamped = [[raw, tmin] | max, tmax] | min %}
            {% set stepped = (clamped * 2) | round(0) / 2 %}
            {{ stepped }}
      # Make sure it's ON in cool mode — but ONLY if it isn't already, so we
      # never cycle it. The heat pump cycles its own compressor to hold the
      # setpoint; we never turn it on/off based on temperature.
      - choose:
          - conditions:
              - condition: template
                value_template: "{{ states(climate_entity) != hvac_mode }}"
            sequence:
              - action: climate.set_hvac_mode
                target:
                  entity_id: "{{ climate_entity }}"
                data:
                  hvac_mode: "{{ hvac_mode }}"
      # Keep the setpoint current as the dew point drifts. The unit regulates
      # itself to this target; it's only turned off when the toggle goes off.
      - action: climate.set_temperature
        target:
          entity_id: "{{ climate_entity }}"
        data:
          temperature: "{{ target_temp }}"

  # --- OPTIONAL: switch everything OFF when you disable the toggle --------
  # Delete this block if you'd rather keep manual control when disabled.
  - alias: "Heat pump + circulation – off when control disabled"
    id: heatpump_dewpoint_off_disabled
    mode: single
    triggers:
      - trigger: state
        entity_id: input_boolean.dewpoint_control
        to: "off"
    actions:
      - action: climate.set_hvac_mode
        target:
          entity_id:
            - climate.heat_pump_indoor
            - climate.thermostat_thermostat
        data:
          hvac_mode: "off"

  # --- Circulation pump: force HEAT @ 35 C so the pump runs continuously ---
  # The circulation thermostat only gates the pump (NOT the heat pump). In
  # auto @ 25 C it won't call for heat, so the pump idles. Heat @ 35 C keeps
  # it always calling -> pump always on. Re-asserts if something resets it.
  - alias: "Circulation pump – force heat 35 while enabled"
    id: circulation_force_heat_35
    mode: single
    triggers:
      - trigger: state
        entity_id: input_boolean.dewpoint_control
        to: "on"
      - trigger: time_pattern
        minutes: "/5"
      - trigger: state
        entity_id: climate.thermostat_thermostat   # re-assert if it drifts
    conditions:
      - condition: state
        entity_id: input_boolean.dewpoint_control
        state: "on"
      - condition: template
        value_template: >-
          {{ states('climate.thermostat_thermostat') != 'heat'
             or (state_attr('climate.thermostat_thermostat', 'temperature') | float(0)) != 35 }}
    actions:
      - action: climate.set_hvac_mode
        target:
          entity_id: climate.thermostat_thermostat
        data:
          hvac_mode: heat
      - action: climate.set_temperature
        target:
          entity_id: climate.thermostat_thermostat
        data:
          temperature: 35
